Static Scheduling Techniques Static Scheduling Techniques
m Local scheduling (within a basic block)
m Loop unrolling
m Software pipelining (modulo scheduling)
m Trace scheduling
m Predication
ECE 463/521,ECE 463/521, ProfsProfs.. ConteConte,, RotenbergRotenberg andand GehringerGehringer, Dept. of ECE,, Dept. of ECE, NC State UniversityNC State University Lec. 27-
Loop Unrolling Loop Unrolling (1 of 2)(1 of 2)
m Unroll the loop (e.g., four times)
Loop: L.D F0, 0(R1) ADD.D F4, F0, F S.D F4, 0(R1) ADDI R1, R1, # BNE R1, xxx, Loop
Loop: L.D F0, 0(R1) ADD.D F4, F0, F S.D F4, 0(R1) L.D F6, 8(R1) ADD.D F8, F6, F S.D F8, 8(R1) L.D F10, 16(R1) ADD.D F12, F10, F S.D F12, 16(R1) L.D F14, 24(R1) ADD.D F16, F14, F S.D F16, 24(R1) ADDI R1, R1, # BNE R1, xxx, Loop
More registers needed!
Benefits:
- Less dynamic instruction overhead (ADD/BNE)
- Fewer branches ⇒⇒ larger basic block: can reschedule operations more easily
Loop: L.D F0, 0(R1) L.D F6, 8(R1) L.D F10, 16(R1) L.D F14, 24(R1) ADD.D F4, F0, F ADD.D F8, F6, F ADD.D F12, F10, F ADD.D F16, F14, F S.D F4, 0(R1) S.D F8, 8(R1) S.D F12, 16(R1) S.D F16, 24(R1) ADDI R1, R1, # BNE R1, xxx, Loop
14 cycles/4 iterations (3.5 cycles/iteration)
5 cycles/iteration
ECE 463/521,ECE 463/521, ProfsProfs.. ConteConte,, RotenbergRotenberg andand GehringerGehringer, Dept. of ECE,, Dept. of ECE, NC State UniversityNC State University Lec. 27-
Loop Unrolling Loop Unrolling (2 of 2)(2 of 2)
m Positives/negatives
u (+) Larger block for scheduling
u (+) Reduces branch frequency
u (+) Reduces dynamic instruction count (loop overhead)
u (–) Expands code size
u (–) Have to handle excess iterations (“strip-mining”)
ECE 463/521,ECE 463/521, ProfsProfs.. ConteConte,, RotenbergRotenberg andand GehringerGehringer, Dept. of ECE,, Dept. of ECE, NC State UniversityNC State University Lec. 27-
Strip-mining Strip-mining
m Suppose that our loop requires 10 iterations,
and we can unroll only 4 of the iterations.
m If we go through our unrolled loop 3 times,
how many iterations (of the original loop)
would we be performing?
m If we go through our unrolled loop twice, how
many iterations (of the original loop) would
we be performing?
Iterations:
Prel: L.D F0, 0(R1) ADD.D F4, F0, F S.D F4, 0(R1) L.D F6, 8(R1) ADD.D F8, F6, F S.D F8, 8(R1) ADD R1, R1, 16 BNE R1, xxx, Prel
m So, we need to add some prelude code, e.g.,
ECE 463/521,ECE 463/521, ProfsProfs.. ConteConte,, RotenbergRotenberg andand GehringerGehringer, Dept. of ECE,, Dept. of ECE, NC State UniversityNC State University Lec. 27-
Static Scheduling Techniques Static Scheduling Techniques
m Local scheduling (within a basic block)
m Loop unrolling
m Software pipelining (modulo scheduling)
m Trace scheduling
m Predication
ECE 463/521,ECE 463/521, ProfsProfs.. ConteConte,, RotenbergRotenberg andand GehringerGehringer, Dept. of ECE,, Dept. of ECE, NC State UniversityNC State University Lec. 27-
Software PipeliningSoftware Pipelining (1 of 5)(1 of 5)
mm^ Symbolic loop unrollingSymbolic loop unrolling
u The instructions in a loop are taken from different
iterations in the original loop.
Iteration 0
Iteration 1
Iteration 2
Iteration 3
Iteration 4
Software
Pipelined
Iteration
This slide borrowed from Per Stenström, Chalmers University, Stockholm, Sweden, Computer Architecture, Lecture 6.
ECE 463/521,ECE 463/521, ProfsProfs.. ConteConte,, RotenbergRotenberg andand GehringerGehringer, Dept. of ECE,, Dept. of ECE, NC State UniversityNC State University Lec. 27-
Software Pipelining Software Pipelining (5 of 5)(5 of 5)
m Positives/negatives
u (+) No dependences in loop body
u (+) Same effect as loop unrolling (hide latencies), but don’t
need to replicate iterations (code size)
u (–) Still have extra code for prologue/epilogue (pipeline
fill/drain)
u (–) Does not reduce branch frequency
ECE 463/521,ECE 463/521, ProfsProfs.. ConteConte,, RotenbergRotenberg andand GehringerGehringer, Dept. of ECE,, Dept. of ECE, NC State UniversityNC State University Lec. 27-
Static Scheduling Techniques Static Scheduling Techniques
m Local scheduling (within a basic block)
m Loop unrolling
m Software pipelining (modulo scheduling)
m Trace scheduling
m Predication
ECE 463/521,ECE 463/521, ProfsProfs.. ConteConte,, RotenbergRotenberg andand GehringerGehringer, Dept. of ECE,, Dept. of ECE, NC State UniversityNC State University Lec. 27-
Trace SchedulingTrace Scheduling (1 of 3)(1 of 3)
Creates a sequence of instructions that are
likely to be executed—a trace.
Two steps:
l Trace selection: Find a likely sequence of
basic blocks ( trace ) across statically
predicted branches (e.g. if-then-else).
l Trace compaction: Schedule the trace to be
as efficient as possible while preserving
correctness in the case the prediction is
wrong.
This slide and the next one have been borrowed from Per Stenström, Chalmers University, Stockholm, Sweden,Computer Architecture, Lecture 6.
ECE 463/521,ECE 463/521, ProfsProfs.. ConteConte,, RotenbergRotenberg andand GehringerGehringer, Dept. of ECE,, Dept. of ECE, NC State UniversityNC State University Lec. 27-
Trace SchedulingTrace Scheduling (2 of 3)(2 of 3)
A[i]:=B[i]+C[i]
A[i] =0?
B[i]:= X
C[i]:=
T F
l The leftmost sequence is
chosen as the most likely
trace.
l The assignment to B is
control-dependent on the
if statement.
l Trace compaction has to
respect data dependencies.
l The rightmost (less likely)
trace has to be augmented
with fixup code.
ECE 463/521,ECE 463/521, ProfsProfs.. ConteConte,, RotenbergRotenberg andand GehringerGehringer, Dept. of ECE,, Dept. of ECE, NC State UniversityNC State University Lec. 27-
Trace Scheduling Trace Scheduling (3 of 3)(3 of 3)
m Select most common path – a trace
u Use profiling to select a trace
u Allows global scheduling, i.e., scheduling across
branches
u This is speculation because schedule assumes certain
path through region
u If trace is wrong (other paths taken), execute repair
code
u Efficient static branch prediction key to success
u Yields more instruction-level parallelism
Trace to be scheduled b[i] = 〈〈 old value 〉〉 a[i] = b[i] + c[i] b[i] = 〈〈 new value 〉〉 c[i] = if (a[i] != 0) goto A B:
A: restore old b[i] X maybe recalculate c[i] goto B
Repair code b[i] = 〈〈 old value 〉〉 a[i] = b[i] + c[i] if (a[i] = 0) then b[i] = 〈〈 new value 〉〉 // common case else X c[i] =
Original code
ECE 463/521,ECE 463/521, ProfsProfs.. ConteConte,, RotenbergRotenberg andand GehringerGehringer, Dept. of ECE,, Dept. of ECE, NC State UniversityNC State University Lec. 27-
Static Scheduling Techniques Static Scheduling Techniques
m Local scheduling (within a basic block)
m Loop unrolling
m Software pipelining (modulo scheduling)
m Trace scheduling
m Predication
