Waveshare LCD
REV. NO. REV. DATE DESCRIPTION OF REVISION PAGE REMARK 0 20/10/07 INITIAL RELEASE ALL
Waveshare LCD
•Display construction…………… •Display mode……………………… •Display type……………………… •Backlight…………………………… •Viewing direction………………… •Operating temperature…………… •Driving voltage…………………… •Driving method…………………… •Type………………………………… •Number of data line……………… •Connector……………………………
16 Characters * 2 Lines TN/STN Positive Transflective LED(B/5.0V) 6 o’clock Indoor Single power 1/16 duty,1/5 bias COB (Chip On Board) 8-bit parallel Pin
ITEM WIDTH HEIGHT THICKNESS UNIT Module size 80.0 36.0 14.0(MAX) mm Viewing area 73.8 27.1 - mm Construction 5*7 dots Size 2.95 4.35 - mm Pitch 3.65 5.05 - mm Size 0.55 0.5 - mm Pitch 0.6 0.55 - mm Diameter of mounting hole 2.7 mm Weight About 50 g
Dot
character
Waveshare LCD
0 ℃~+60 ℃ -55℃~+125 ℃
Waveshare LCD
Parts QA Dept. LCD Mfg. Dept. LCM QA Dept. Parts
Soldering
Soldering Inspection
Parts Acceptance Inspection
LCM Assembling
High Temp. Test
Heat Cycle Aging
Inspection
Storage/Shipping
Outgoing Inspection
Packaging
Soldering Condition
100% Inspection (ex. 50^ Function & Appearance:℃)
Dimension: Random Sampling^ 1. Function,Appearance &
Waveshare LCD
•Operating life time:Longer than 50000 hours (at room temperature without direct irradiation of sunlight)
•Reliability Characteristics:
Item Test Criterion High temp 60℃ / 200 Hrs Low temp. -10℃ / 200 Hrs High humidity 40℃ * 90%RH / 200 Hrs Thermal shock (^) (30min) (5min) (30min) (5min)-10℃→25℃→60℃→25℃ /5 Cycles Vibration 1.Operating time: Thirty minutesexposure in each direction (x, y, z) 2.Sweep Frequency (1min):10Hz→ 55Hz→10Hz 3.Amplitude: 0.75mm double amplitude
(^5) consumption should beTotal current below double ofinitial value (^5) should be withinContrast ratio initial value±50% 5 No defect in cosmetic andoperational function is allowable
Waveshare LCD
Waveshare LCD
Waveshare LCD
f^ E-CYCLE osc =250KHz SCREENCLEAR 0 0 0 0 0 0 0 0 0 1 1.64ms CURSORRETURN 0 0 0 0 0 0 0 0 1 * DDRAM AD=0, Return,Content Changeless 1.64ms INPUT SET 0 0 0 0 0 0 0 1 I/D S^ Set moving direction of cursor,Appoint if move 40us DISPLAYSWITCH 0 0 0 0 0 0 1 D C B Set display on/off,cursor on/off,blink on/off 40us SHIFT 0 0 0 0 0 1 S/C R/L * * display,DDRAM changeless^ Remove cursor and whole 40us FUNCTIONSET 0 0 0 0 1 DL N F * * Set DL,display line,font 40us CGRAMAD SET 0 0 0 1 ACG send receive data Set CGRAM AD, 40us DDRAMAD SET 0 0 1 ADD send receive data Set DDRAM AD, 40us READ CT^ BUSY/AD 0 1 BF^ AC^ Executing internal function,reading AD of CT 40us CGRAM/DDRAM Write data from CGRAM orDDRAM 40us DATA WRITE^1 0 DATA WRITE CGRAM/DDRAM Read data from CGRAM orDDRAM 40us DATA READ^1 1 DATA READ DDRAM: Display data RAMCGRAM: Character ACG: CGRAM ADGenerator RAM ADD: DDRAM AD & CursorAD AC: Address counter forDDRAM & CGRAM
changing^ E-cycle frequency.with main Example:If fcp or fosc =270KHz 250/27040us x =37us
I/D=1: Increment Mode; I/D=0: Decrement ModeS=1: Shift S/C=1: Display Shift; S/C=0: Cursor ShiftR/L=1: Right Shift; R/L=0: Left Shift DL=1: 8DN=1: 2R DL=0: 4DN=0: 1R F=1: 5x10 Style;BF=1: Execute Internal Function; F=0: 5x7 Style BF=0: Command Received
Waveshare LCD
Waveshare LCD
be reshaped, which willconductive rubber may
LCD may be shifted or cause defects.
Pressure on the metallicframe and PCB may deform the conductive rubber orbreak the liquid crystal cell and back light, whichwill cause defects.
Don’t Press the Metallic Frame and Disassemble the LCM
Avoid static electricity.
Slowly Peel Off Protective Film!
Please be sure to groundhuman body and electric It is preferable to useapploances during work. conductive mat on tableand wear cotton clothes or conduction processedfiber. Synthetic fiber is not recommended.
Avoid Static Electricity! Wear Gloves While Handing!
LCD deteriorates.
Keep Away From Extreme Heat and Humidity!
When attaching with theheat seal or anisontropically conductive film, wipe offwith alcohol before use.
Alcohol
Use Alcohol to Clean Terminals!
GLOVE
It is preferable to wear glovesto avoid damaging the LCD. Please do not touch electrodeswith bare hands or make them dirty.
Waveshare LCD
Note that the presence ofwaterdrops or dew in the LCD panel may deterioratethe polarizer or corrade electrode.
Don’t Drop Water on LCD!
Precaution in Soldering LCD Module
Basic instructions: Solder I/O terminals only.Use soldering iron without leakage. (1)Soldering condition to I/O terminalsTemperature at tip of the iron: 280± 10 ℃ Soldering time: 3~4 sec.Type of solder: Eutectic solder (containing colophony-flux) Please do not use flux because it may soak into LCD Module or contaminate it.It is preferable to peel off protective film on display surface after soldering I/O
(2)Remove connector or cableterminals is finished. *When you remove connector or cable soldered to I/O terminals, please confirmthat solder is fully melted. If you remove by force, electrodes at I/O terminals may *It is recommended to use solder suction machine.be damaged(or stripped off).
Long-term Storage If it is necessary to store LCD modules for a long time, please comply with thefollowing procedures. If storage condition is not satisfactory, display(especially polarizer) may be deterioratedor soldering I/O terminals may become difficult(some oxide is generated at I/O terminals plating).1.Store as delivered by Optrex 2.If you store as unpacked,put in anti-static bag,seal its opening and store where it isnot subjected to direct sunshine nor fluorescent lamp. 3.Store at temperature 0 to +35sheets for storage temperature range and humidity condition.℃ and at low humidity.Please refer to our specification
Long-term Storage Please use power supply with built-in surge protection circuit.
