Altai
A8
-
Ei
Super WiFi Base Station
ALL
-
IN
-
ONE (base unit, antennas, &
external cables)
The Altai A8
-
E
i
Super WiFi Base Station is the world’s
leading WiFi outdoor access point with integrated
multi-beam antenna array optimized for maximum
coverage from a minimum number of installation
sites. This eliminates external RF cabling between
base station and antennas and makes installation
simple.
The A8-Ei is a multi-radio base station utilizing
smart antenna
technologies and a
patented signal
processing algorithm to
provide the industry’s
best coverage per base
station, especially in non-
line
-
of sight (NLOS)
Whether deployed for a single location, a campus
area or city-wide network coverage, the Altai A8-Ei is
designed to minimize the total cost of ownership with
significant savings in network equipment,
broadband access, planning, site acquisition and
installation.
The Altai A8-Ei serves as last mile infrastructure for a
wide range of wireless broadband access
applications. It provides low deployment cost and
fast provisioning of WiFi systems with the greatest
coverage and bandwidth per installed base station.
The A8-Ei Super WiFi Base Station can also be
deployed in conjunction with existing 3G mobile
networks to provide low cost high bandwidth mobile
data offloading solution. The A8-Ei can be co-
located with existing 3G cell sites allowing
immediate WiFi provisioning at much lower
acquisition and operating costs.
As an integral part of our Super WiFi network infrastructure, key benefits of the Altai A8-Ei include:
Backhaul resilience and 1+1 protective switching
Adaptive interference control mitigates the influence from
surrounding interfering sources
Supports real-time applications such as VoIP, video-
streaming and interactive gaming with minimal latency
Standard 802.11b/g access and 802.11a wireless
backhaul
Fast Ethernet or integrated 802.11a wireless backhaul
Remote configuration through the Altai Wireless
Management System (AWMS)
Base station and antenna array in one integrated unit,
eliminating RF cabling work. Simple installation at
rooftop, wall, tower and lamppost
Extended coverage in a Non-Line-of-Sight (NLOS)
environment which matches the foot print of most 3G
deployments in dense urban environments
Multi-beam Smart Antenna Technology to provide
superior signal strength and link budget in dense urban
environment deployments
Multi-radio platform to maximize both uplink/downlink
performance and access redundancy
© 2010 Altai Technologies Limited. All rights reserved.
