Thank you for purchasing this DENON product. To ensure proper operation, please read these owner’s manual carefully before using the product. After reading them, be sure to keep them for future reference.
Getting started
Accessories
Check that the following parts are supplied with the product.
q Owner’s manual ...................................................................... 1 w Warranty (for North America model only) ................................ 1 e Service network list ................................................................. 1 r Remote control unit (RC-1149) ................................................ 1 t R03/AAA batteries ................................................................... 2 y AM loop antenna ..................................................................... 1 u FM indoor antenna .................................................................. 1
r y u
About this manual
n Operation buttons
The operations described in this manual are based mainly on remote control operation.
n Symbols
v This symbol indicates a reference page on which related information is described. This symbol indicates a supplementary information and tips for operations.
NOTE This symbol indicates points to remember operations or function limitations.
n Illustrations
Note that the illustrations in these instructions are for explanation purposes and may differ from the actual unit.
Simple version (Simple setup guide) ··························
Basic version ··········································································
Connections ················································································· Important information ································································· Connecting an HDMI-compatible device ···································· Connecting a TV·········································································· Connecting a Blu-ray Disc player / DVD player ··························· Connecting a set-top box (Satellite tuner/cable TV) ···················· Connecting a digital camcorder ·················································· Connecting a portable player ······················································ Connecting a control dock for iPod ············································· Connecting an antenna ······························································· Playback (Basic operation) ························································· Important information ································································· Playing a Blu-ray Disc player/DVD player ···································· Playing a portable player ····························································· Playing an iPod®^ ········································································· Tuning in radio stations ······························································· Selecting a listening mode (Surround mode) ·························· Standard playback ······································································· Multi channel stereo playback ···················································· Virtual playback ··········································································· Stereo playback ·········································································· Direct playback ···········································································
Advanced version ·······························································
Speaker installation/connection (Other than 5.1-channel) ····· Install ·························································································· Connect ······················································································ Playback (Advanced operation) ················································· Convenient functions ·································································· How to make detailed settings ·················································· Menu map ·················································································· Examples of front display ··························································· Input Setup ················································································· Option Setup··············································································· Adjusting the sound field effects ················································ Information ·················································································
Information ·············································································
Part names and functions ··························································· Front panel ·················································································· Display ························································································ Rear panel ··················································································· Remote control unit ···································································· Other information ······································································· Trademark information································································ Surround ····················································································· Explanation of terms ··································································· Troubleshooting ·········································································· Resetting the microprocessor ···················································· Specifications ··············································································
Contents
Getting started ·············································································· Accessories ·················································································· About this manual ········································································· Features ························································································ Cautions on handling ····································································
Cautions on handling
- Before turning the power switch on Check once again that all connections are correct and that there are no problems with the connection cables.
- Power is supplied to some of the circuitry even when the unit is set to the standby mode. When going on vacation or leaving home for long periods of time, be sure to unplug the power cord from the power outlet.
- About Condensation If there is a major difference in temperature between the inside of the unit and the surroundings, condensation (dew) may form on the operating parts inside the unit, causing the unit not to operate properly. If this happens, let the unit sit for an hour or two with the power turned off and wait until there is little difference in temperature before using the unit.
- Cautions on using mobile phones Using a mobile phone near this unit may result in noise. If that occurs, move the mobile phone away from this unit when it is in use.
- Moving the unit Turn off the power and unplug the power cord from the power outlet. Next, disconnect the connection cables to other system units before moving the unit.
- About Care
- Wipe the cabinet and control panel clean with a soft cloth.
- Follow the instructions when using a chemical cleaner.
- Benzene, paint thinner or other organic solvents as well as insecticide may cause material changes and discoloration if brought into contact with the unit, and should therefore not be used.
Features
Fully Discrete, identical quality and power for all
5 channels (110 W x 5ch)
The unit is equipped with a power amplifier that plays back high- fi delity sound in surround mode with equal quality and power for all channels, true to the original sound. The power amplifier circuit adopts a discrete-circuit configuration that achieves high-quality surround sound play back.
Supports HDMI 1.4a with 3D, Deep Color and
x.v.Color function
This unit can output 3D video signals input from a Blu-ray Disc player to a TV that supports a 3D system.
4-HDMI inputs and 1-output
The unit is equipped with 4 HDMI input connectors for connecting devices with HDMI connectors, such as a Blu-ray Disc player, game machine, HD video camera, etc.
High Definition Audio Support
The unit is equipped with a decoder which supports high-quality digital audio format for Blu-ray Disc players such as Dolby TrueHD, DTS-HD Master Audio, etc.
Dock connecrivity for iPod® and network
streaming
If an optional DENON control dock for iPod (ASD-3N, ASD-3W, ASD-51N or ASD-51W) is connected to this unit, you can listen to Internet radio or enjoy music and photos stored in your PC.
zAn Internet connection environment is required.
Speakers
Carefully check the left (L) and right (R)
channels and + (red) and – (black) polarities
on the speakers being connected to the
this unit, and be sure to interconnect the
channels and polarities correctly.
Connecting the speaker cables Peel off about 0.03 ft/10 mm of sheathing from the tip of the speaker cable, then either twist the core wire tightly or terminate it.
When using a banana plug Tighten the speaker terminal firmly before inserting the banana plug.
NOTE
- Connect so that the speaker cable core wires do not protrude from the speaker terminal. The protection circuit may be activated if the core wires touch the rear panel or if the + and – sides touch each other ( v page 48 “Protection Circuit”).
- Never touch the speaker terminals while the power supply is connected. Doing so could result in electric shock.
- Use speakers with the speaker impedances shown below.
Speaker terminals
Speaker impedance FRONT CENTER 6 – 16 Ω SURROUND
Install
1 2 3 4 5
This unit can perform 2.0/2.1 to 7.1-channel surround playback.
Here, we explain setup using the example of 5.1-channel speaker
playback.
FL FR
SW
C
SL SR
120˚
22 – 30˚
Listening position
FL Front speaker (L) • Install the surround speakers in a position 2 to 3 ft (60 to 90 cm) higher than ear level.
Surround speaker
2 – 3 ft / 60 – 90 cm
G Viewed from the side H
Front speaker
FR Front speaker (R) C Center speaker SW Subwoofer SL Surround speaker (L) SR Surround speaker (R)
1 Connect
1 2 3 4 5 2
The “Simple version” describes the installation, connection and setup methods for 5.1-channel speakers.
See page 25 for the installation and connection for speakers other than 5.1-channel speakers.
Basic version
Advanced version
Information
Simple version
Blu-ray Disc player and TV
Use only an HDMI (High Definition Multimedia Interface) cable that bears the HDMI
logo (a certified HDMI product). Using a cable without the HDMI logo (an uncertified
HDMI product) may result in abnormal playback.
When outputting Deep Color or 1080p, etc., we recommend you use “High Speed
HDMI cable” or “High Speed HDMI cable with Ethernet” for enhanced high-quality
playback.
*/
)%.* 065
)%.*
To household power outlet (AC 120 V, 60 Hz)
Power cord
TV
Blu-ray Disc player
HDMI cable (sold separately)
HDMI cable (sold separately)
NOTE
- Do not plug in the power cord until all connections have been completed.
- Do not bundle power cords together with connection cables. Doing so can result in humming or noise.
Connect
SL SR
FL FR
SW
C
Speaker cables (sold separately)
Audio cable (sold separately)
Subwoofer with built-in amplifier
The “Simple version” describes the installation, connection and setup methods for 5.1-channel speakers.
See page 25 for the installation and connection for speakers other than 5.1-channel speakers.
Basic version
Advanced version
Information
Simple version
Set up speakers
Remote control operation buttons
Move the cursor (Up/Down/Left/Right) Confirm the setting Return to previous menu
4
Use ui to select a speaker, and use o p to select a
detailed setting.
Items to be set are shown below.
Front Set the front speaker size.
- Large : Use a large speaker that can adequately play back low frequencies.
- Small : Use a small speaker that has inadequate playback capacity for low frequencies.
- When “SW” is set to “No”, “Front” is automatically set to “Large”.
- When “Front” is set to “Small”, “Center”, “Surround“ and “S.B(Pre)” can not be set to “Large”.
Center Set the presence and size of the center speaker.
- Large : Use a large speaker that can adequately play back low frequencies.
- Small : Use a small speaker that has inadequate playback capacity for low frequencies.
- None : Select when a center speaker is not connected.
“Large” is not displayed when “Front” is set to “Small”.
Surround Set the presence and size of the surround speakers.
- Large : Use a large speaker that can adequately play back low frequencies.
- Small : Use a small speaker that has inadequate playback capacity for low frequencies.
- None : Select when the surround speakers are not connected.
- When “Surround” is set to “Large”, “S.B(Pre)” can be set to “Large”.
- When “Surround” is set to “None”, “S.B(Pre)” can automatically set to “None”.
1
Press MENU.
The menu is displayed on the display of this unit.
Speaker Setup
2
Use ui to select “Speaker Setup”, and then press
ENTER.
Speaker Config.
3
Use ui to select “Speaker Config.”, and then press
ENTER.
Front :•Large–
NOTE Do not use the outward shape of the speaker to determine selection of a “Large” or “Small” speaker. Instead, use the frequencies set in “Crossover Frequency” (vpage 9) as the standard for determining bass reproduction capability.
S.B(Pre) (Surround Back)
Set the presence, size and number of surround back speakers.
- Large : Use a large speaker that can adequately play back low frequencies.
- Small : Use a small speaker that has inadequate playback capacity for low frequencies.
- None : Select when the surround back speakers are not connected.
Even when the “S.B(Pre)“ setting is other than “None”, sound may not be emitted from the surround back speaker, depending on the playback source. In this case, make “Surround Parameter”
- “SB CH OUT” (vpage 35) setting other than “OFF”.
SW (Subwoofer) Set the presence of a subwoofer.
- Yes : Use a subwoofer.
- No : Select when a subwoofer is not connected.
When “Front” is set to “Small”, “SW” is automatically set to “Yes”.
5
Press ENTER to enter the setting.
Speaker Config.
Speaker Config.
Default settings are underlined.
Set up speakers
Remote control operation buttons
Move the cursor (Up/Down/Left/Right) Confirm the setting Return to previous menu
3
Use ui to select “Mode”, and use
o p to select a detailed setting.
Mode :• LFE –
Mode Select low range signals to be reproduced by subwoofer.
- LFE : The low range signal of the channel set to “Small” speaker size is added to the LFE signal output from the subwoofer.
- LFE+Main : The low range signal of all channels is added to the LFE signal output from the subwoofer.
- “Mode” can be set when “Speaker Config.” – “SW” (vpage 7) is set to “Yes”.
- Play music or a movie source and select the mode offering the strongest bass.
- Select “LFE+Main” if you want the bass signals to always be produced from the subwoofer.
NOTE If “Front” and “Center” for “Speaker Config.” are set to “Large”, and “Mode” is set to “LFE”, no sound may be output from the subwoofers, depending on the input signal or selected surround mode.
4
Press ENTER to enter the setting.
Bass Setting
1
Use ui to select “Bass Setting”, and
then press ENTER.
Bass Setting
LFE •120Hz–
2
Use o p to select the frequency.
LFE Set LFE signal playback range.
- 80Hz / 90Hz / 100Hz / 110Hz / 120Hz / 150Hz / 200Hz / 250Hz
1
Use ui to select “Distance”, and
then press ENTER.
Distance
Feet :• 1ft–
2
Use o p to change the step (minimum
variable distance).
1ft : For changing in 1-foot steps. 0.1ft : For changing in 0.1-foot steps.
Bass Setting
Default settings are underlined.
Distance
Default settings are underlined.
3
Use ui to select a speaker, and use
o p to select distance.
FL / FR / C / SW / SL / SR / SBL z / SBR z Select the speaker. zWhen the “Speaker Config.” – “S.B(Pre)” (vpage 7) setting is set to “None”, “SBL” and “SBR” is not displayed.
- 0.0ft – 60.0ft : Set the distance.
- The speakers that can be selected differ depending on the “Speaker Config.” (vpage 7) settings.
- Default settings : FL / FR / C / SW : 12.0 ft SL / SR / SBL / SBR : 10.0 ft
- Set the difference in the distance between the speakers to less than 20 ft.
NOTE Speakers set to “None” in “Speaker Config.” (vpage 7) are not displayed.
4
Press ENTER to enter the setting.
Distance
Play back disc
1 2 3 4 5 5
1
Press BD to switch an input source
for a player used for playback.
2
Play the component connected to
this unit.
Make the necessary settings on the player (language setting, subtitles setting, etc.) beforehand.
3
Adjust the sound volume.
VOL d ··········································· Volume up VOL f ······································ Volume down MUTE ·················································· Muting
4
Set the listening mode.
Set the listening mode according to the playback contents (cinema, music, etc.) or according to your liking (vpage 21 “Selecting a listening mode (Surround mode)”).
When power is switched to standby
Press POWER OFF.
G Power indicator status in standby mode H
You can also switch the power to standby by pressing ON/STANDBY on the main unit.
NOTE During power standby, a minimal amount of power is consumed. To totally cut off the power, remove the power cord from the power outlet.
Basic
version
Advanced version
Information
Basic version
Simple version
F Connections v page 12
F Playback (Basic operation) v page 17
F Selecting a listening mode (Surround mode) v page 21
n Refer to the pages indicated below for information on connecting and playing back the various
media and external devices.
Audio and video Connection Playback
TV v page 12, 13 –
Blu-ray Disc player v page 12, 14 v page 17
DVD player v page 12, 14 v page 17
Set-top box (Satellite tuner or cable TV) v page 12, 14 –
Game console v page 12 –
Digital camcorder v page 15 –
Control dock for iPod v page 16 v page 18
Portable player v page 15 v page 17
Audio Connection Playback
Radio v page 16 v page 20
For speaker connections, see page 4.
Basic version
Here, we explain the connections and basic operation methods for this unit.
Advanced version
Simple version
Information
Basic version
Connecting to a device equipped with a DVI-D connector
When an HDMI/DVI conversion cable (sold separately) is used, the HDMI video signals are converted to DVI signals, allowing connection to a device equipped with a DVI-D connector.
NOTE
- No sound is output when connected to a device equipped with a DVI-D connector. Make separate audio connections.
- Signals cannot be output to DVI-D devices that do not support HDCP.
- Depending on the combination of devices, the video signals may not be output.
n Settings related to HDMI connections
Set as necessary. For details, see the respective reference pages.
Other Setup ( v page 34)
Make settings for HDMI udio output.
NOTE
The audio signals output from the HDMI connectors are only the HDMI input signals.
Connecting an HDMI-compatible device
Connecting a TV
- Select the connector to use and connect the device.
- For instructions on HDMI connections, see “Connecting an HDMI-compatible device” (vpage 12).
To listen to TV audio through this device, use the optical digital connection.
NOTE If the VIDEO input connector and S-VIDEO input connector are to be used, be sure to connect the MONITOR output connector of the unit and the VIDEO input connector of the TV, using a video cable.
Cables used for connections
Video cable (sold separately) Video cable (Yellow) Audio cable (sold separately) Optical cable
*/
7%& 7%&
"6%* 015*$"- 065
TV
Set this to change the digital input connector to which the input source is assigned. “Input Assign” (vpage 31)
in Set as Necessary
Connecting a Blu-ray Disc player / DVD player
- You can enjoy video and audio from a Blu-ray Disc or DVD.
- Select the connector to use and connect the device.
- For instructions on HDMI connections, see “Connecting an HDMI-compatible device” (vpage 12).
NOTE
If the DVD VIDEO input connector is to be used, be sure to connect the MONITOR output connector of the unit and the VIDEO input connector of the TV, using a video cable.
Cables used for connections
Video cables (sold separately) Video cable (Yellow) Audio cable (sold separately)
Audio cable (White) (Red) R
L R
L
L R
L R
7%&0 "6% "6%*
065 065
7*%&
Blu-ray Disc player / DVD player
Set this to change the digital input connector to which the input source is assigned. “Input Assign” (vpage 31)
in Set as Necessary
For HD audio (Dolby TrueHD, DTS-HD, Dolby Digital Plus and DTS Express) playback, connect with HDMI (vpage 12 “Connecting an HDMI-compatible device”).
Connecting a set-top box (Satellite tuner/cable TV)
- You can watch satellite or cable TV.
- Select the connector to use and connect the device.
- For instructions on HDMI connections, see “Connecting an HDMI-compatible device” (vpage 12).
NOTE If the SAT/CBL VIDEO input connector is to be used, be sure to connect the MONITOR output connector of the unit and the VIDEO input connector of the TV, using a video cable.
Cables used for connections
Video cables (sold separately) Video cable (Yellow) Audio cables (sold separately)
Audio cable
(White) (Red) R
L R
L
Coaxial digital cable (Orange)
L R
L R
7%&0 "6% "6%*
065 065
7*%& 065
$0"9*"-
Satellite Tuner/Cable TV
Set this to change the digital input connector to which the input source is assigned. “Input Assign” (vpage 31)
in Set as Necessary
Connecting an antenna
- Connect the FM antenna or AM loop antenna supplied with the unit to enjoy listening to radio broadcasts.
- After connecting the antenna and receiving a broadcast signal (vpage 20 “Listening to FM/AM broadcasts”), fi x the antenna with tape in a position where the noise level becomes minimal.
q w e
FM outdoor antenna
75 Ω Coaxial cable
Ground
AM outdoor antenna
AM loop antenna (supplied)
Black White
FM indoor antenna (supplied)
Direction of broadcasting station
n AM loop antenna assembly
1
Put the stand section
through the bottom of the
loop antenna from the
rear and bend it forward.
Stand Square hole Projecting part
Loop antenna
2
Insert the projecting part
into the square hole in
the stand.
n Using the AM loop antenna
Suspending on a wall
Suspend directly on a wall without assembling. Nail, tack, etc.
Standing alone
Use the procedure shown left to assemble.
NOTE
- Do not connect two FM antennas simultaneously.
- Even if an external AM antenna is used, do not disconnect the AM loop antenna.
- Make sure the AM loop antenna lead terminals do not touch metal parts of the panel.
- If the signal has noise interference, connect the ground terminal (GND) to reduce noise.
- If you are unable to receive a good broadcast signal, we recommend installing an outdoor antenna. For details, inquire at the retail store where you purchased the unit.
Connecting a control dock for iPod
- Connect a control dock for iPod to the unit to enjoy video and music stored on an iPod.
- For a control dock for iPod, use ASD-11R, ASD-3N, ASD-3W, ASD-51N and ASD-51W made by DENON (sold separately).
- For instructions on the control dock for iPod settings, refer to the control dock for iPod’s operating instructions.
R L
R (^) L
"4%/
Control dock for iPod
zUse the AV/Control Cable supplied with the DENON control dock for iPod.
z
Set this to change the digital input connector to which the input source is assigned. “Input Assign” (vpage 31)
in Set as Necessary
Advanced version
Simple version
Information
Basic version
Playback (Basic operation)
n Playing a Blu-ray Disc player/DVD player
(vpage 17)
n Playing a portable player (vpage 17)
n Playing an iPod®^ (vpage 18)
n Tuning in radio stations (vpage 20)
Selecting a listening mode (Surround mode)
(vpage 21)
n Selecting the input source (vpage 17)
n Adjusting the master volume (vpage 17)
n Turning off the sound temporarily (vpage 17)
Playback (Advanced operation) (vpage 27)
Important information
Before starting playback, make the connections between the different components and the settings on the receiver.
NOTE
Also refer to the operating instructions of the connected components when playing them.
Selecting the input source
Press the input source select button
(DVD, BD, TUNER, DOCK, SAT/CBL,
GAME, V.AUX z , TV) to be played
back.
The desired input source can be selected directly.
z For operation with the main unit, use V.AUX/PORTABLE.
Adjusting the master volume
Use VOL df to adjust the volume.
n When the “Volume Display” setting
( v page 33) is “Relative”
G Adjustable range H
- – – –80.5dB – 18.0dB
n When the “Volume Display” setting ( v page 33) is
“Absolute”
G Adjustable range H 0.0 – 99.
- The variable range differs according to the input signal and channel level setting.
You can also operate via the main unit. In this case, perform the following operations. Turn MASTER VOLUME to adjust the volume.
Turning off the sound temporarily
Press MUTE.
- The sound is reduced to the level set at “Mute Level” (vpage 33).
- To cancel, press MUTE again. Muting can also be canceled by adjusting the master volume.
Playing a Blu-ray Disc player/DVD
player
The following describes the procedure for playing Blu-ray Disc player/ DVD player.
1
Prepare for playback.
q Turn on the power of the TV, subwoofer and player. w Change the TV input to the input of this unit. e Load the disc in the player.
2
Press POWER ON to turn on
power to the unit.
3
Press BD or DVD to switch an
input source for a player used for
playback.
4
Play the component connected to this unit.
Make the necessary settings on the player (language setting, subtitles setting, etc.) beforehand.
Playing a portable player
The following describes the procedure for playing portable player.
1
Connect the portable player to
this unit ( v page 15 “Connecting
a portable player”).
2
Press POWER ON to turn on
power to the unit.
3
Press V.AUX to switch the input
source to “V.AUX”.
4
Play the component connected to this unit.
