AGENDA

• Introduction – Basics of Data Communication

• Serial Communication

• Ethernet Communication

• Modbus Protocol

• DNP Protocol

DATA C OMMUNICATION

Communication Link

  • Symplex
  • Half-Duplex
  • Full-Duplex

Broadband

  • Many different channels
  • Ex: Home cable

Baseband

  • Single channel
  • Entire bandwidth of link transmits one bit

Character Encoding

  • ASCII
    • Ex A = 00101000
  • Hexadecimal
    • Base of 16
    • Digits 0-9 and letters A-F

SERIAL C OMMUNICATION

  • Only 2 wires are required between transmitter and receiver
  • 8 electrical on/off voltage signals are sent in a sequence w.r.t a time base
  • Data transfer is done bit by bit arranged in a particular format - Baud Rate - A measure of how fast serial data is moving between devices per second - Data Packet - Characters transmitted one after the other in short bursts. - Contains address, data and error check

PARITY E RROR

  • Errors inevitably occur in the transfer of data due to noise and timing errors
  • Parity error checking is a very simple form of error detection
  • Limited to detection of a single bit error
  • User can use even or odd parity

NETWORKS

NETWORK TOPOLOGIES

  • SCADA communication topologies classification:
    • Physical Topology: Physical connection of wires between the devices in a network.
    • Logical Topology: Refers to how the information is through the network among the devices.
    • In many instances, the logical topology is same as the physical topology.
  • Physical topologies:
    • Point to point and multi-point (multi-drop)
    • Bus topology
    • Ring topology
    • Star topology
    • Mesh topology

NETWORK TOPOLOGIES

Bus topology

  • Commonly used for master station communication
  • Each node is connected to a single or redundant bus that carries the message
  • Advantages: Cost effective, reliable and easy to expand
  • Disadvantages: Bus failure and delay in message transmission during heavy traffic.

NETWORK TOPOLOGIES

  • Ring topology
  • All the nodes including the master form a ring

STANDARDS

  • Need for a common set of rules

C OMPATIBILITY

  • The pure physical connection standard
  • The existence of complementary software standards used in conjunction with the physical standards
  • Confirmability of physical connection and software to open system interconnected model

OPEN SYSTEM INTERCONNECTION

OPEN SYSTEM INTERCONNECTION

DATA L INK

  • Provides service that allow communication between devices
  • Framing or separation of messages
  • Error detection
  • Correction mechanism
  • Addressing mechanism
  • Direct exchange of frames among devices on a single

communications channel

OPEN SYSTEM INTERCONNECTION

N ETWORK

  • Responsible for device-to-device data delivery and optimal routing across multiple data links

TRANSPORT

  • Guaranteed-delivery messaging service ensuring data is error free and correctly sequenced
  • Allowing process-to process communications between devices across a network or multiple networks

S ESSION

  • Mechanism for the establishment of a communication session between applications running within the devise

RS 232/

  • 1969: EIA developed and introduced RS 232
  • Defined electrical and mechanical details of the interface for serial transfer of characters between Data Terminal Equipment such as printers and computers to Data Communication Equipment.
  • A lot of flexibility open to the designer of the hardware regarding the rules of data exchange

RS 232/

FOR THE RECEIVER

  • Logic one = - 3V to -25V
  • Logic zero = +3V to +25V
  • Undefined signal = > -3V and <+3V

SLEW RATE

  • It will take sometime for the transmitter output to swing from +25V to -25V. This delay is called the slew rate
  • Slew rate is one of the factors that limits the maximum transmission rate
