Structural Description

 Components and their instantiation

 Configuration

 Components in package

Example for Structural Description

Entity mux is

port (d0,d1,sel: in std_logic; q: out std_logic);

end;

Architecture str of mux is

-- Component declaration

component and_comp port (a,b: in std_logic; c: out std_logic); end component;

component or_comp port (a,b: in std_logic; c: out std_logic); end component;

component inv_comp port (a: in std_logic; b: out std_logic); end component;

signal i1,i2,sel_n:std_logic;

-- Component specification

for U1: inv_comp Use Entity work.inv_comp(rtl);

for U2,U3: and_comp Use Entity work.and_comp(rtl);

for U4: or_comp Use Entity work.or_comp(rtl);

Component Declaration

• For a VHDL component to be instanced with structural VHDL, it first has to be

declared

• This is done in the concurrent declaration part of the architecture
• Syntax:

component <entity_name>

[generic(<generic-association-list>);]

port(<port-association-list>);

end component;

• Port_list in the component declaration must be identical to that in the

component’s entity

• The best way of guaranteeing this is to copy the entity to the component

declaration or vice versa

• Generic parameters do not need to be declared in the component declaration

Component Instantiation

• component_instantiation_statement ::= instantiation _label : instantiated_unit [ generic_map_aspect ] [ port_map_aspect ] ;
• Example:
  • u_myent: ENTITY

work.my_entity(bhv)

PORT MAP (I1 => S1 , I2 => S2 ) ;

• The entity my_entity is directly instantiated
• The signals I1 and I2 of my_entity are connected with the local signals S1 and S

Component instantiation

U1: nand_comp port map (a => wire1, b => wire2, c => wire3);

• The component nand_comp is instanced and given the name U
• Each name of a new instance of nand_comp must be an unique name

Configuration I

• A configuration binds an architecture to an entity
• In a lot of CAE tools there is not configuration at all or the integrated tool has

configuration functionality

• In the next example the configuration is described in VHDL language
• The entity mux has two different architectures, the rtl and bhv
• The configuration specifies, which is to be simulated
  • The name of the configuration which results in the rtl architecture being simulated is mux_rtl
  • while that for the bhv architecture is mux_bhv

entity mux is

port (a,b,c,d: in std_logic_vector(3 downto 0);

sel : in std_logic_vector(1 downto 0);

q : in std_logic_vector(1 downto 0));

end ;

Configuration III

architecture rtl of mux is begin process (a,b,c,d,sel) begin case sel is when “00” => q<=a; when “01” => q<=b; when “10” => q<=c; when others => q<=d; end case ; end process ; end ;

Configuration IV

-- Configuration for architecture bhv

configuration bhv of mux is for bhv end for ; end bhv;

-- Configuration for architecture rtl configuration rtl of mux is

for rtl end for ;

end rtl;

• Depending on which of the configurations is compiled, architecture bhv or rtl will be simulated
• The component specification is a simplified form of the configuration
• The component specification is placed in hte declaration part of the architecture for the component to be simulated
• The configuration is mainly used in design of simulatable models, in case of hardware design the tools avoid it

Components in packages I

• If the components are defined in packages , no component declaration is needed in the architecture when the component is instantiated
• Example:

package mypack is function minimum (a,b: in std_logic_vector) return std_logic_vector; component c1 port (clk,resetn,din: in std_logic; q1,q2: out std_logic); end component ; component c2 port (a,b: in std_logic; q: out std_logic); end component ; end mypack;

package body mypack is function minimum (a,b: in std_logic_vector) return std_logic_vector is begin if a<b then return a; else return b; end if ; end minimum; end mypack;

Components in packages II

• To use the component the declaration of the package is needed in the beginning of the VHDL code, only:

library ieee; use ieee.std_logic_1164.ALL; use work.mypack.ALL;

entity ex is port (clk,resetn: in std_logic; d1,d2: out std_logic; a,b: in std_logic_vector(3 downto 0); q1,q2,q3: out std_logic; q4: out std_logic_vector(3 downto 0)); end ;

Architecture rtl of ex is begin U1: c1 port map (clk,resetn,d1,q1,q2); U2: c2 port map (d1,d2,q3); q4<=minimum(a,b); end ;
